Adjusta-Vibe 18

Descaling metal castings

Adjusta-Vibe 18

As low as $665.00
  • Adjusta-Vibe 18
  • Comes in 115V (Domestic) & 230V (International)
  • 12 " bowl capacity is .18 cubic feet
  • Designed for heavy duty use to deburr or polish
  • Features adjustable amplitude
  • Can be used with all medias
  • Has a drain
  • Rated Horsepower: 115v and 230v - 0.19
Replacement parts may be ordered or you may contact Customer Service for a factory repair quote and RMA number

CLICK HERE FOR REPLACEMENT PARTS FOR AV-18

Please be certain you have selected the correct voltage for your location. United States typically uses 115V.

Categories: ,
In stock
SKU
AdjustaVibe18

Adjusta-Vibe 18

The AV-18 has a capacity of .18 cubic feet. It has adjustable amplitude and is designed for heavy duty use with all medias. The 12-inch bowl is equipped with drains. This model has many features of our larger machines for processing metal parts, whether for deburring or polishing. Used for descaling metal castings, Deburring metal stampings and machined parts, cutting radii on sharp edges of metal parts. Grinding and polishing baroque gemstones from rough chips. smoothing and polishing preformed cabochons and small slabs.

Shipping weight 22 pounds; shipping volume 2.13 cubic feet, 15” x 18” x 15”.






Tech Tips

 Adjusta-Vibe Amplitude Adjustment

The amplitude (the amount of movement of the bowl) determines the force with which the tumbling media will act upon the workpieces. The greater the amplitude, the more aggressive the tumbling action will be. The Adjusta-Vibe makes it possible to adjust the amplitude of the tumbler to match the job to be done. The adjustable weight system will produce a tumbling action that ranges from mild to aggressive.

Before
After




WARNING: This product can expose you to lead, which is known to the State of California to cause cancer, birth defects, or other reproductive harm. For more information go to www.p65warnings.ca.gov

More Information
Part Number 23024r and 24113r
Motor 115v 60Hz 1.7 Amps Wattage power 120W / 230v is 50Hz 0.8 Amps Wattage power 120W Noise Level 82db
Best Use Deburring metal stampings and machined parts
Helpful Hint see tech tips
Unit Weight 22 lbs
Pack Carton Size 2.13 cubic feet
Box Measurements 15” x 18” x 15”
Bowl Capacity Size .18 cubic feet
Bowl Diameter 12 inches
Bowl Height To Lid 4.25 Inches
Bowl Width To Shaft 4 inches
